| Name: | Insulated Shield Tostrengen Core Sector Elevator Cable | Applicable: | Elevator Equipment |
|---|---|---|---|
| Rated Voltage: | AC 300/500V | Opening Way: | CENTER |
| Transportation: | Sea Transportation | Keywords: | Insulated Shield Tostrengen Core Sector Elevator Cable |
| Type: | Insulated Shield Tostrengen Core Sector Elevator Cable | Model: | Insulated Shield Tostrengen Core Sector Elevator Cable |
| ハイライト: | insulated elevator cable 300/500V,shield tostrengen core elevator cable,sector elevator spare parts cable |
||
Tostrengen Industrial-Grade Insulated Shield Core Sector Elevator Cable – Heavy-Duty, High-Safety Power Transmission For Demanding Lift Systems
The Insulated Shield Tostrengen Core Sector Elevator Cable is engineered for superior performance in industrial, commercial, and high-rise elevator systems. Featuring advanced insulated shielding technology, it ensures maximum electrical safety, EMI/RFI interference resistance, and long-term reliability in harsh operating conditions.
✔ Heavy-Duty Insulation – High-grade materials protect against abrasion, moisture, and temperature fluctuations (-40°C to 90°C).
✔ EMI/RFI Shielding – Reduces signal interference for smooth elevator control system operation.
✔ Flexible & Fatigue-Resistant – Multi-stranded copper conductors enhance bend tolerance for continuous movement.
✔ Fire-Resistant & Low-Smoke – Complies with UL, CE, and RoHS safety standards for public and industrial use.
✔ Custom Lengths & Configurations – Available in various gauges and shielding options to fit core sector elevator requirements.
High-rise commercial elevators
Industrial freight lifts & material handling systems
Hospital & emergency elevator systems
Smart buildings with automated control
| Product name: | elevator with accompanying cable |
| Product standard: | GB/T5023.6IEC60227-6 |
| Rated voltage: | TVVB 300/500V 0.75-1.0mm2 |
| Operating temperature Range: | Used under the normal conditions,the temperature of conductoris at lower than 70°C; Cables are suitable for ambient temperature between-15to+40'C; |
| Mechanical properties: Free hanging length: | ≤80m |
| Travelling speed: | ≤4m/s |
|
Type voltage class
|
Cores×Section
(mm2)
|
Type of conductor
(mm)
|
Max conductor
resistance
(Ω/km)
|
Insulation resistance
at 70℃
|
|
TVVBPG
300/500V
|
24×0.75+2P/2×0.75
|
0.6
|
≤26.0
|
≥0.011
|
|
30×0.75+2P/2×0.75
|
0.6
|
≤26.0
|
≥0.011
|
|
|
36×0.75+2P/2×0.75
|
0.6
|
≤26.0
|
≥0.011
|
|
|
48×0.75+2P/2×0.75
|
0.6
|
≤26.0
|
≥0.011
|
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
